A new generation of intelligent AC/DC Din Rail Power Supply

Jul 22 , 2021
EPS75-240W series AC/DC Power Supply is a new generation of intelligent Din rail type switching power supply.The power supply can be widely used in new energy charging piles, power cabinets and industrial control cabinets, with smaller volume, higher efficiency and more energy saving.

EPS75-240W series features:

The standard shape: 125.2mm * 113.5mm * 40MM
Input voltage: 85-265Vac
The isolation voltage: 3000Vac
The built-in active PFC function and DC OK relay contact
The 150% high peak load capacity
The protection type: short circuit / overload / over voltage / temperature
The natural air cooling
The installation guide: TS-35/7.5 or TS-35/15
The industrial grade EN61000-6-2 tolerance
The EMC Class B with EN55022

The safety regulations in accordance with UL/EN 60950

As a professional manufacturer of AC and DC power supplies.Provide AC/DC converter 2.5W-100W and enclosed power supply 35W-350W.High efficiency,low cost,welcome to consult!
