Transient voltage protector and EMI Filtering TSL50S10
Product Information:
Model: TSL50S10
Dimension: 50.8mm×40.6mm×12.7mm
Input voltage range: 0–50Vdc,16.5-50Vdc continuous work
Transient protection MIL-STD-1275 A/B/D
EMI filtering: Common mode: 26dB ,Different mode: 35dB
1500Vdc Input / Output to Base / FG
–40°C to +100°C Case temperature
Warranty Period: 5-year
Electrical Specification:
Input characteristic:
Input voltage range: 0-50 Vdc,16.5-50Vdc continuous work
Recommand input voltage range: 18-36Vdc Continuous
Output characteristic:
Output Voltage Range: 16 -49.5Vdc ,24Vdc typ.
Output current : 10A @125W max. limit ,8A: Continuous ,10A:100ms after startup
External output capacitance: 1000μF typ. @FIG1 Cout
General characteristic:
Efficiency: 98% typical @Full load
Dielectric withstand: 1500Vdc Input / Output to Base / FG
EMI : Common mode: 26dB ,Different mode: 35dB
Case Temperature: -40℃ to +100℃Storage Temperature: -55℃ to +125℃
Our Services:
15 years experience of converter industry.
5 Years Warranty.
Fast response for any question within 24 hours.
Full technical support before/after sales.
Customized products available (OEM, ODM).
CE,ROHS Compliance
