DC-DC Converter YHD50-200W Series
The YHD50-200W Series DC/DC Converters are widely used in Telecommunications, Electronic Data Processing, Distributed Power Architecture.
Product Information:
Model: YHD50-200W
Half-Brick (61.0mm×57.9mm×12.7mm)
Positive Logic, Remote on/off
Input Under voltage Protection
Output Current Limit Protection(OCP)
Output Over Voltage Protection(OVP)
Over Temperature Protection (OTP)
Output Voltage Adjust Range:±10 % of the rated output voltage
Output Short-circuit Protection, hiccup, auto-recoveryIsolation Voltage: 1500Vdc /1min/1mA (Input-Output)
1050Vdc /1min/1mA (Input-Case)
500Vdc /1min/1mA (Output- Case)
Operating Case Temp: -40℃to +100℃
Warranty Period: 5-year
Electrical Specification:
Input characteristic:
Input Voltage Range: 18-36Vdc, 36-72Vdc, 66-160Vdc
Output characteristic:
Output voltage/Current : see tables - technical datasheet
Line Regulation: ±0.2% max.
Load Regulation: ±0.5% max.
Ripple and Noise: 100mV-300mV Max
Temperature Coefficient: ±0.02%/℃
General characteristic:
Switching Frequency: 300KHz(typ.)
Efficiency: 88% typical.
MTBF: 1.5×106h @Bellcore TR332,Tc=25℃
Case Temperature: -40℃ to +100℃
Storage Temperature: -55℃ to +105℃
Our Services:
15 years experience of converter industry.
5 Years Warranty.
Fast response for any question within 24 hours.
Full technical support before/after sales.
Customized products available (OEM, ODM).
ROHS Certificate or Compliance
FAQ:
Q: what can you buy from us?
A: AC-DC Converter,DC-DC Converter,Power Module, Power Converter,Module Power Supply,isolated dc dc module
Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: Is it acceptable to print my logo on the product?
A: Yes. based on a certain purchase quantity,we can make OEM logo.
Q: Do you offer guarantee for the products?
A: Yes, we offer 2 or 5-year warranty for our products.
Q: What if I cannot find what I need on your products list?
A: What we list are standard types of AC-DC Converter,DC-DC Converter, if can't find what you needed, please tell us, we will send you the technical datasheet on email.
